QWZ5-315/50 Series Pneumatic nruas nres
QWZ5-315/50 yog QWZ5 series pneumatic nruas nres, qhov twg 315 hais txog qhov sib txuam nres nruas txoj kab uas hla ntawm 315mm, thiab 50 qhia txog tus qauv ntawm QG50 lub tog raj kheej, haum rau cov khoom lag luam uas xav tau kev txhim khu kev qha pneumatic braking nrog rau ntawm qhov chaw cua. Hauv qab no yog nws cov ncauj lus kom ntxaws ...
Hauj lwm lawm
QWZ5-315/50 yog QWZ5 series pneumatic nruas nres, qhov twg 315 hais txog qhov sib txuam nres nruas txoj kab uas hla ntawm 315mm, thiab 50 qhia txog tus qauv ntawm QG50 lub tog raj kheej, haum rau cov khoom lag luam uas xav tau kev txhim khu kev qha pneumatic braking nrog rau ntawm qhov chaw cua. Hauv qab no yog nws cov ncauj lus kom ntxaws specification thiab kev ua tau zoo qhia:
Core Technical Specifications
| Parameter | Paub meej |
|---|---|
| Nres nruas txoj kab uas hla | 3 15mm |
| Rated braking torque | Feem ntau 800-1200 N·m (adjustable ntawm lub caij nplooj ntoos hlav quab yuam) |
| Ua haujlwm cua siab | 0.5-0.7 MPa |
| Nres khau clearance | 0.8–1.2 mm (tus kheej- sib npaug, tsis muaj kev hloov kho) |
| Lub tog raj kheej qauv | QG50 pneumatic lub tog raj kheej |
| Nres hauv ob sab phlu | Tsis yog-asbestos semi-metallic, clip- rau kev hloov ceev |
| Ua haujlwm kub ambient | -20℃rau +50 degree |
| txheeb ze humidity | Tsawg dua los yog sib npaug li 90% |
| Lub luag haujlwm ua haujlwm | S3-60% (1200 cycles / teev) lossis S1 ua haujlwm tas li |
| Qhov hnyav | Kwv yees li . 45-50 kg |
| Ua raws li cov qauv | GB6333-86 (kev sib txuas qhov ntev), JB/T6406-2006 (kev xav tau) |
Cov Qauv Tseem Ceeb & Kev Ua Haujlwm Zoo
Kev nyab xeeb & kev ntseeg tau: Fail-kev nyab xeeb tsim-brakes ntawm lub caij nplooj ntoos hlav quab yuam thaum huab cua raug txiav tawm, tiv thaiv kev sib tsoo los ntawm huab cua poob tam sim ntawd. Interlocking khau clearance equalization thiab tsis siv neeg alignment kom ob sab sib npaug, zam ib qho - sab ncoo rub ntawm lub nruas.
Kev saib xyuas tsawg: Cov ntsiab lus tseem ceeb ntawm pob khawm siv tus kheej -lubricating bearings nrog kev sib kis tau zoo, tsis muaj lubrication ntxiv. Clip- ntawm lub hauv paus nres tso cai hloov ceev yam tsis muaj kev cuam tshuam lub cev nres.
ruaj khov braking: QG50 lub tog raj kheej muab kev ua haujlwm du; adjustable caij nplooj ntoos hlav quab yuam enables meej braking torque tuning hloov mus rau txawv loads thiab speeds.
Yooj yim installation: Ntau qhov kev taw qhia mounting muaj, sib xws nrog ntau yam khoom siv hauv kev lag luam, thiab yooj yim rau kev koom ua ke rau hauv cov tsav tsheb uas twb muaj lawm.
Tej kev siv
Dav siv rau kev nrawm nrawm, nres nres nres, thiab kev tiv thaiv kev nyab xeeb ntawm cov tshuab hauv cranes (choj, gantry), siv conveyors, cov khoom siv thauj khoom, thiab cov tshuab metallurgical-zoo tagnrho rau hnyav-lub luag haujlwm, siab{2}} zaus ua haujlwm nrog rau ntawm - qhov chaw compressed cua.
Cov Lus Qhia Txog Kev Kho Mob
Kev tshuaj xyuas txhua hnub: Tshawb xyuas cov pa tawm hauv lub tog raj kheej thiab cov kab cua; xyuas kom meej qhov sib npaug ntawm cov cuab yeej ua haujlwm ib txwm; ntxuav cov plua plav / khib nyiab los ntawm lub nruas thiab hauv ob sab phlu.
Kev saib xyuas ib ntus (3-6 lub hlis): Tshawb xyuas hauv ob sab phlu hnav- hloov thaum thickness qis dua 3 hli; xyuas lub caij nplooj ntoos hlav quab yuam thiab kho yog tias torque txo; xyuas kom nruj ntawm fasteners thiab pins.
Ib puag ncig tshwj xeeb: Rau sab nraum zoov / ntsev-mist/acid-mist tej yam kev mob, siv los tiv thaiv-corrosion txheej los yog xaiv customized los tiv thaiv- qauv corrosion; tshem tawm cov dej noo los ntawm huab cua tsis tu ncua kom tiv thaiv lub tog raj kheej xeb.
Cim npe nrov: qwz5-315/50 series pneumatic nruas nres, Suav teb, manufacturers, tsum, hoobkas, customized
