🛠️ Khoom Muag Khoom: DLZ Series Electromagnetic Log Nres
CovDLZ Seriesyog tsim los rautsis ua haujlwm-kev nyab xeeb (kev nyab xeeb nres)daim ntawv thov, feem ntau yog siv rau ntawm cranes, hoists, thiab chaw nres nkoj machinery los tiv thaiv kev txav mus los thaum muaj hluav taws xob lossis muaj xwm txheej ceev.
Model Correlation: DLZ Series(Electromagnetic Fail-Safe Brake).
Hom: Electromagnetic / Caij nplooj ntoos hlav-Applied (Fail-Safe).
Kev Ua:
Braking (Power Off):Lub caij nplooj ntoos hlav muaj zog ua rau cov khau khau tiv thaiv lub log lossis tsheb ciav hlau.
Tso Tawm (Power On):Lub electromagnetic kauj yog energized los rub lub armature thiab tso tus nres.
Feature tseem ceeb: Kev ua haujlwm "Fail-Safe".Yog tias lub zog poob lawm, tus nres tau txais los tuav lub nra ntawm qhov chaw.
📋 Cov Ntsiab Lus Qhia Tshwj Xeeb (Ib yam rau DLZ Series)
表格
| Parameter | Specification |
|---|---|
| Series | DLZ (Electromagnetic Fail{0}}Safe Brake) |
| Qauv Variant | DLZ-25(Qhia qhov loj / quab yuam theem) |
| Fais fab mov | DC 24V / 110V / 220V 2(Feem ntau rectified) |
| Txoj kev nres | Caij nplooj ntoos hlav Applied / Electromagnetic Release |
| Rwb thaiv tsev Class | H Class(High thermal kam rau ua) |
| Qib tiv thaiv | IP54 / IP65(Dust thiab splashproof) |
| Teb Sijhawm | Ceev ceev(Feem ntau <0.15s) |
✨ Cov yam ntxwv tseem ceeb
High Safety Factor:Tsim tshwj xeeb rau kev nyab xeeb- daim ntawv thov tseem ceeb. Lub caij nplooj ntoos hlav- siv lub tshuab ua kom muaj kev sib tsoo txawm tias lub zog tsis ua haujlwm.
Zog txuag:Ntau tus qauv siv a"High-Kev Tswj Xyuas Tam Sim No"qhov system. Lawv siv lub siab tam sim no los pib tso tus nres thiab tom qab ntawd hloov mus rau qhov tuav qis qis, txo qis kev tsim hluav taws xob thiab kev siv hluav taws xob.
Kev tsim kho muaj zog:Ua nrog cam khwb cia hlau los yog hlau Cheebtsam los tiv thaiv kev cuam tshuam thiab hnyav kev lag luam ib puag ncig (plua plav, ya raws, kev co).
Phau ntawv tso tawm:Nruab nrog phau ntawv tso tawm qib lossis ntsia hlau rau kev saib xyuas lossis kev ua haujlwm kub ntxhov thaum tsis muaj hluav taws xob.
Wear Compensation:Nta tsis siv neeg lossis phau ntawv hloov kho mechanisms los them nyiaj rau cov khau khau khiab, kom ntseeg tau tias kev ua haujlwm zoo sib xws.
🏭 Ib Daim Ntawv Thov
DLZ series yog dav siv hauv:
Nyiaj siv ua haujlwm cranes & Hoists:Rau choj, trolley, thiab hoist mechanisms.
Chaw nres nkoj Machinery:Roj Hmab-nkig gantry cranes thiab nkoj unloaders.
Lifts & Lifts:Rau thaum muaj xwm ceev braking thiab tuav.
Cov cuab yeej siv mining:Conveyor brakes thiab winches.
💡 Kev Pabcuam thiab Kev Ua Haujlwm
Air Gap Check:Tsis tu ncua xyuas qhov sib txawv ntawm armature thiab electromagnet. Yog tias qhov sib txawv loj heev (vim hnav), lub zog hluav taws xob yuav tsis txaus los tso tus nres.
Coil Health:Tshawb xyuas cov electromagnetic coil rau cov cim ntawm kev kub hnyiab lossis kub dhau, tshwj xeeb tshaj yog tias tus nres yog chattering (vibrating).
Hnav khaub ncaws:Saib xyuas cov thickness ntawm kev sib txhuam hauv ob sab phlu. Hloov lawv ua ntej lawv hnav mus rau cov hlau thaub qab kom tsis txhob ua rau lub log lossis tsheb ciav hlau puas.
Phau ntawv tso tawm:Xyuas kom meej tias phau ntawv tso tawm mechanism tsis muaj kev cuam tshuam, vim nws yog qhov tseem ceeb rau kev saib xyuas kev nyab xeeb.
