YT1 - 90Z/6 yog ib tug tswv cuab ntawm YT1 series electro - hydraulic thrusters. Nws yog lub zog compact thiab txhim khu kev qha - tsav tsheb, feem ntau yog siv los ua lub tshuab tsav tsheb rau lub nruas thiab disc nres. Nws kuj muaj ntau yam kev siv hauv kev tsav tsheb tswj kev lag luam li qub thiab cov khoom siv clamping. Cov hauv qab no yog cov ncauj lus kom ntxaws txog nws cov ntsiab lus tseem ceeb, daim ntawv thov Scope, thiab cov hauv paus ntsiab lus ua haujlwm:
Core ParametersCov qauv no tau ruaj khov thiab txhim khu kev qha kev ua tau zoo, uas tuaj yeem ua tau raws li qhov xav tau ntawm cov khoom siv hluav taws xob feem ntau ntawm nruab nrab - qhov loj ntawm braking thiab actuating mechanisms. Cov parameter tshwj xeeb yog raws li nram no:
| Hom Parameter | Tus nqi tshwj xeeb |
|---|---|
| Rated zog | 90kg (sib npaug rau 900N) |
| Rated mob stroke | 60 hli |
| Lub cev muaj peev xwm | 0.25 kWm |
| Rated voltage | 380V (customizable raws li yuav tsum tau rau txawv voltage thiab zaus qib) |
| Rated tam sim no | 0.62A |
| Lub sijhawm ua haujlwm | 0.8s (lub sijhawm nce) |
| Ua haujlwm zaus | 720c/h |
| Qhov hnyav | 28kg ua |
| Rwb thaiv tsev thiab tiv thaiv qib | Rwb thaiv tsev qib yog Class B, thiab plhaub tiv thaiv qib yog IP54 |
Siv tau ib puag ncig thiab Scope
Siv tau ib puag ncig: Nws tuaj yeem ua haujlwm ruaj khov hauv qhov ntsuas kub ntawm -20℃txog 45 degree, thiab cov huab cua txheeb ze yuav tsum tsis pub tshaj 90%. Qhov siab ntawm qhov chaw siv yuav tsum ua raws li GB755 - 2000 tus qauv. Nws yuav tsum tau muab sau tseg tias nws tsis tuaj yeem siv nyob rau hauv ib puag ncig uas muaj hluav taws kub, tawg, lossis corrosive gases thiab plua plav. Yog hais tias nws yog siv sab nraum zoov los yog nyob rau hauv ib tug corrosive ib puag ncig, ib tug anti-corrosion hom ntawm cov qauv no yuav tsum tau xaiv. Thaum siv, nws yuav tsum tau ntim nrog DB - 25 hydraulic roj ua ntej.
Daim ntawv thov Scope: Nws yog dav siv los ua tus tsav tsheb ntawm YWZ series nruas nres thiab ntau yam disc nres. Nws yog feem ntau nruab rau hauv cov khoom nqa xws li cranes thiab hoists hauv cov chaw tsim kho thiab cov chaw tsim khoom. Tsis tas li ntawd, nws tseem tuaj yeem siv rau kev tsav tsheb ntawm kev lag luam li qub thiab kev tswj xyuas tsawg dua 90℃steering mechanisms, uas ua lub luag haujlwm tseem ceeb hauv kev ua kom muaj kev nyab xeeb thiab kev tswj xyuas cov khoom siv.
Txoj Cai Ua HaujlwmCov khoom sib xyaw ua ke lub cev muaj zog, lub twj tso kua mis centrifugal, thiab lub tog raj kheej roj. Nws paub txog kev hloov pauv hluav taws xob thiab kev sib kis los ntawm kev koom tes ntawm cov tshuab hluav taws xob thiab hydraulic, thiab cov txheej txheem ua haujlwm tau muab faib ua ob theem ntawm kev txuas ntxiv thiab rov pib dua:
Extension (lub zog - rau, nres nres): Thaum lub thruster yog powered, lub built - nyob rau hauv lub cev muaj zog pib ua hauj lwm thiab tsav lub centrifugal impeller tig. Qhov kev sib hloov no tsim lub siab nyob rau hauv lub piston chamber, uas nqus cov roj hydraulic los ntawm sab sauv ntawm lub piston mus rau sab qis. Nyob rau hauv lub laub ntawm cov roj hydraulic, lub piston, thawb pas nrig, thiab crossbeam nce nrawm. Tom qab ntawd, lub caij nplooj ntoos hlav load yog compressed los ntawm lub lever mechanism, thiab tus tsav nres yog qhib raws li ua kom tiav lub hwj chim tso zis kev txiav txim.
Rov pib dua (lub zog - tawm, nres nres): Thaum lub thruster yog powered, lub cev muaj zog thiab centrifugal impeller nres tam sim ntawd, thiab lub siab nyob rau hauv lub hydraulic system ploj. Lub sijhawm no, lub piston sai sai nqis los ntawm kev sib xyaw ua ke ntawm lub zog elastic ntawm lub caij nplooj ntoo hlav thiab nws lub ntiajteb txawj nqus. Cov roj hydraulic ntws rov qab mus rau sab sauv ntawm lub piston dua, thiab lub laub pas nrig retracts synchronously. Thaum kawg, lub lever mechanism tsav lub nres kom clamp, paub lub braking los yog rov pib dua ntawm cov cuab yeej.
