DCPZ20-400 Electromagnetic Disc Nres|Fail-Safe Safety Nres
DCPZ20-400 belongs rau DCPZ series hnyav-lub luag haujlwm electromagnetic caliper disc nres. Nws siv lub caij nplooj ntoos hlav siv braking thiab electromagnetic tso tawm cov qauv tsis muaj kev nyab xeeb, feem ntau yog siv rau kev nres tsheb nres, nres thaum muaj xwm txheej ceev thiab txo qis ntawm kev nqa, kev xa khoom thiab winding machinery. Nws tuaj yeem nruab nrog cov hlau nplaum sib txuam kom paub txog kev ruaj ntseg braking tiv thaiv.
Hauj lwm lawm
Product Overview
DCPZ20-400 electromagnetic disc nres yog lub luag haujlwm hnyav ib txwm kaw muaj kev nyab xeeb nres nrog classiccaij nplooj ntoos hlav thov braking, electromagnetic tso tawmtxoj cai. Nws yog txawm peem rau nrog matched DT400-400Y electromagnet li tsav tsheb. Thaum fais fab tuag, electromagnet rub armature kom kov yeej lub caij nplooj ntoos hlav preload, cais cov nres nres los ntawm nres disc, thiab tso tus nres kom cov cuab yeej khiav tau ib txwm.
Thaum lub hwj chim raug txiav tawm, qhov hluav taws xob tsis ua haujlwm lossis lub zog hluav taws xob cuam tshuam, ua tau - nyob rau hauv siab - lub zog springs tam sim ntawd thawb lub nres nres kom clamp lub 400mm brake disc thiab ua tiav tsis siv neeg nres thaum muaj xwm ceev. Nws tau tsim- hauv kev sib txhuam tsis siv neeg lub ncoo hnav cov nyiaj them, ua kom ruaj khov ncoo-disc clearance thaum lub sijhawm ua haujlwm ntev-. Txais siv tsis yog-asbestos kev sib txhuam pads, lub caliper nres no txhawb siab - zaus cyclic braking, compact hauv cov qauv thiab yooj yim rau installation, haum rau hnyav load industrial braking scenarios.
Core Features & Product Advantages
Ua tsis tiav -Safe Ib txwm Kaw Kev Nyab Xeeb Kev Nyab Xeeb: Caij nplooj ntoos hlav siv braking, tsis siv neeg nres thaum fais fab tuag. Tiv thaiv cov cuab yeej khiav tawm thiab thauj khoom poob, ua tau raws li cov qauv kev nyab xeeb thoob ntiaj teb.
Automatic Pad Wear Compensation: Ua tau -nyob rau hauv qhov sib txawv them nyiaj mechanism, cia li them nyiaj rau kev sib txhuam ntawm lub ncoo, ua kom tsis txhob nres nres, txo cov kev hloov kho ntawm phau ntawv.
Heavy-Lub luag haujlwm nres nres: Tsim los rau 20mm tuab nres disc thiab 400mm disc txoj kab uas hla, muab qhov loj thiab ruaj khov braking torque rau hnyav inertia khoom.
Quick Pad Hloov: Ntxig hom kev sib txhuam pads, tuaj yeem hloov tau sai yam tsis muaj kev cuam tshuam tag nrho cov nres caliper, ua kom luv downtime thiab tu nqi.
Siab -Frequency Stable Braking: rhiab heev teb, du braking tsis muaj kev cuam tshuam los yog jitter, haum rau nquag pib- nres ua hauj lwm tej yam kev mob.
Phau ntawv tso tawm muaj nuj nqi muaj: Phau ntawv tso tawm cov cuab yeej siv rau kev ua haujlwm kub ntxhov thaum lub hwj chim tsis ua hauj lwm, yooj yim rau ntawm - kev txij nkawm.
Tsis yog -asbestos Friction Pad: Hnav-resistant, ruaj khov kev sib txhuam coefficient, tsis tshua muaj plua plav thiab ib puag ncig tus phooj ywg.
Compact Caliper Structure: Me me hneev taw, yooj yim rau nruab rau ntawm cov cuab yeej siv nrog tsawg qhov chaw teeb tsa.
Daim Ntawv Thov Scope
DCPZ20-400 electromagnetic caliper disc nres yog dav siv rau cov tshuab uas yuav tsum tau nres thaum muaj xwm ceev, nres tuav thiab deceleration braking:
Nyiaj siv ua haujlwm cranes, gantry cranes thiab hnyav- lub luag haujlwm nqa winches
Siv conveyors thiab bulk khoom conveying cov cuab yeej hauv kuv, chaw nres nkoj thiab cog
Metallurgical machinery, steel coil winding thiab unwinding nro tswj
Cable, ntawv thiab textile winding ntau lawm kab
Kev tsim kho tshuab thiab hnyav -cov khoom siv hluav taws xob kis tau tus mob
Tag nrho cov khoom siv hauv kev lag luam xav tau lub zog- tawm kev nyab xeeb nres thiab tuav tuav
Ua kom tiav Technical Parameters
| Yam khoom | Tus nqi Parameter |
|---|---|
| Full Model | DCPZ20-400 Electromagnetic Caliper Disc nres |
| Hom Series | DCPZ Series Feem ntau kaw Electromagnetic Disc Nres |
| Matching Nres Disc Diameter | 400 hli |
| Sib piv Nres Disc Thickness | 20 mm |
| Matched Electromagnet | DT 400-400 Y |
| Ua haujlwm Voltage | AC380V (AC220V yeem) |
| Txoj Cai Ua Haujlwm | Caij nplooj ntoos hlav Applied Braking, Electromagnetic Release |
| Ua haujlwm Ambient Kub | -20℃~ +40 degree |
| txheeb ze humidity | Tsawg dua lossis sib npaug li 90% (Tsis muaj condensation) |
| Friction Pad Khoom | Tsis yog-asbestos semi-hlau hnav-cov ntaub ntawv tiv taus |
| Ua hauj lwm hom | Thaum muaj xwm ceev nres, nres tuav, deceleration braking |
| Max ua haujlwm zaus | 1200 cycles / h |
| Execution Standard | JB/T10917-2008 |
Txoj Cai Ua Haujlwm
Fais fab-Ntawm tso tawm (Lub Xeev Ua Haujlwm Li Cas)Thaum electromagnet energized, magnetic quab yuam rub lub armature los ua ke thiab kov yeej preload quab yuam ntawm lub build- nyob rau hauv springs. Lub nres nres cais tawm ntawm 20mm tuab 400mm nres nres, nres tag nrho tso tawm, thiab cov cuab yeej siv tshuab tuaj yeem ua haujlwm ib txwm tsis muaj kev cuam tshuam.
Caij nplooj ntoos hlav Braking (Kev Kub Ceev & Chaw Nres Tsheb)Thaum lub hwj chim muab txiav tawm los yog hluav taws xob tsis ua hauj lwm, electromagnet poob magnetic attraction tam sim ntawd. Siab -lub zog compression springs thawb lub caliper mechanism, ua kom cov brakes nruj nreem clamp lub nres nres. Txhim khu kev sib txhuam braking torque yog tsim los nres kev sib hloov thiab xauv lub load, tsis txhob muaj kev nyab xeeb xws li kev thauj khoom poob thiab cov khoom siv zawv zawg.
Cim npe nrov: dcpz20-400 electromagnetic disc nres|kev ruaj ntseg nres nres, Suav teb, manufacturers, lwm tus neeg, Hoobkas, customized
