Electro Hydraulic nres
YWZ4 Series Electro Hydraulic Nres nrog YT1 Thruster Electro-hydraulic brakes yog dav siv nyob rau hauv deceleration los yog nres nres ntawm cov neeg kho tshuab tsav tsheb li lifting, metallurgy, mining, ports, docks, thiab siv machinery. Kev ua tau zoo yog kev nyab xeeb thiab txhim khu kev qha, lub braking yog ...
Hauj lwm lawm
YWZ4 Series Electro Hydraulic Nres nrog YT1 Thruster
Electro-hydraulic brakes yog dav siv nyob rau hauv deceleration los yog nres nres nres ntawm mechanical tsav tsheb li lifting, metallurgy, mining, ports, docks, thiab siv machinery.
Qhov kev ua tau zoo yog muaj kev nyab xeeb thiab txhim khu kev qha, lub braking ruaj khov, thiab qhov ua haujlwm zaus yog siab. Lub ntsiab viav vias pob khawm yog nruab nrog tus kheej-lubricating bearings, uas muaj kev sib kis tau zoo thiab lub neej ntev. Tsis tas yuav lubrication thaum siv.
| Nres hom | Thruster hom | Braking torque (Nm) | Qhov Loj (mm) | Qhov hnyav (kg) | |||||||||||||||
A | b | C | D | d | E | F | G1 | G2 | H | h1 | i | K | M | n | G3 | ||||
YWZ4- 100/18 | YT1-18z/2 | 40 | 269 | 70 | 137 | 100 | 13 | 130 | 75 | 125 | 125 | 384 | 100 | 40 | 110 | 144 | 6 | 50 | 20 |
Txc4- 150/25 | YT1-25z/4 | 100 | 307 | 90 | 154 | 150 | 17 | 175 | 100 | 170 | 170 | 437 | 140 | 60 | 150 | 144 | 8 | 70 | 26 |
YWZ4- 200/25 | YT1-25z/4 | 200 | 347 | 90 | 154 | 200 | 17 | 210 | 100 | 195 | 195 | 437 | 170 | 60 | 175 | 156 | 8 | 95 | 30 |
YWZ4- 300/25 | YT1-25z/4 | 320 | 447 | 140 | 160 | 300 | 22 | 290 | 130 | 275 | 275 | 590 | 240 | 80 | 250 | 210 | 10 | 125 | 63 |
YWZ4- 300/45 | YT1-45z/5 | 630 | 459 | 140 | 178 | 300 | 22 | 290 | 130 | 275 | 275 | 590 | 240 | 80 | 250 | 210 | 10 | 125 | 70 |
TSW 4-300/90 | YT1-90z/8 | 750 | 510 | 140 | 210 | 300 | 22 | 320 | 130 | 275 | 275 | 690 | 240 | 80 | 250 | 210 | 10 | 125 | 80 |
YWZ4- 400/45 | YT1-45z/5 | 1000 | 564 | 180 | 220 | 400 | 22 | 370 | 180 | 350 | 350 | 750 | 320 | 130 | 325 | 275 | 12 | 190 | 120 |
TSW 4-400/90 | YT1-90z/8 | 1600 | 595 | 180 | 220 | 400 | 22 | 370 | 180 | 350 | 350 | 750 | 320 | 130 | 325 | 275 | 12 | 190 | 130 |
YWZ4- 400/125 | YT1-125z/10 | 2200 | 670 | 180 | 254 | 400 | 22 | 370 | 180 | 350 | 350 | 847 | 320 | 130 | 325 | 279 | 12 | 190 | 167 |
YWZ4- 500/90 | YT1-90z/8 | 2500 | 670 | 200 | 250 | 500 | 22 | 440 | 200 | 405 | 405 | 919 | 400 | 150 | 380 | 310 | 16 | 225 | 210 |
YWZ4-500/125 | YT1-125z/10 | 2650 | 692 | 200 | 254 | 500 | 22 | 440 | 200 | 405 | 405 | 940 | 400 | 150 | 380 | 310 | 16 | 225 | 220 |
YWZ4- 500/180 | YT1-180z/12 | 3000 | 692 | 200 | 254 | 500 | 22 | 440 | 200 | 405 | 405 | 946 | 400 | 150 | 380 | 310 | 16 | 225 | 235 |
YWZ4- 600/90 | YT1-90z/8 | 3200 | 805 | 240 | 315 | 600 | 26 | 555 | 220 | 500 | 500 | 1087 | 475 | 170 | 475 | 400 | 18 | 250 | 400 |
YWZ4- 600/125 | YT1-125z/10 | 4500 | 827 | 240 | 315 | 600 | 26 | 555 | 220 | 500 | 500 | 1095 | 475 | 170 | 475 | 400 | 18 | 250 | 415 |
YWZ4- 600/180 | YT1-180z/12 | 5000 | 827 | 240 | 315 | 600 | 26 | 555 | 220 | 500 | 500 | 1095 | 475 | 170 | 475 | 400 | 18 | 250 | 430 |
YWZ4- 700/180 | YT1-180z/12 | 8000 | 957 | 280 | 390 | 700 | 34 | 600 | 270 | 575 | 575 | 1248 | 550 | 200 | 540 | 495 | 25 | 315 | 500 |
YWZ4-800/180 | YT1-180z/12 | 10000 | 1094 | 320 | 436 | 800 | 34 | 680 | 320 | 677 | 677 | 1389 | 600 | 240 | 620 | 556 | 25 | 367 | 720 |
YWZ4-800/320 | YT1-320z/12 | 12500 | 1155 | 320 | 436 | 800 | 34 | 680 | 320 | 677 | 677 | 1389 | 600 | 240 | 620 | 556 | 25 | 367 | 885 |
FAQ
Q1: Koj puas yog lub tuam txhab lag luam lossis lub Hoobkas?
A1: Peb yog lub Hoobkas, ib qho ntawm thawj zaug, loj tshaj plaws thiab nto moo nres manufacturers hauv Suav teb.
Q2: Yuav ua li cas txog lub installation?
A2: Muaj cov lus qhia kev teeb tsa khoom lossis cov yeeb yaj kiab. Peb cov engineers xa tuaj tuaj yeem coj koj kev teeb tsa thiab tshuaj xyuas txhua lub sijhawm.
Q3: Koj lub sijhawm xa khoom ntev npaum li cas?
A3: Feem ntau 7-15 hnub tom qab them nyiaj ua ntej.
Q4: Koj puas kuaj tag nrho koj cov khoom ua ntej xa khoom?
A4: Yog lawm, peb ua 100% kev kuaj ua ntej xa khoom.
Q5: Puas yog nws yooj yim mus ntsib koj lub Hoobkas?
A5: Yog lawm, peb txais tos txhua tus neeg siv khoom tuaj xyuas peb lub tuam txhab. Peb kuj muab kev tshaj tawm hauv xov xwm tuaj xyuas peb lub Hoobkas.
Q6: Koj muaj daim ntawv pov thawj dab tsi?
A6: CE, ISO9001
Yog tias koj xav tau cov ntaub ntawv ntxaws ntxaws, thov hu rau Zhongyuan Brake, peb tuaj yeem tsim ntau yam tsis yog tus qauv nres rau cov neeg siv.
Cim npe nrov: electro hydraulic nres, Suav teb, manufacturers, tsum, hoobkas, customized
