CovTYWZ2 Seriesyog ib qho kev txhim kho ntau yam ntawm kev lag luam- qib ko taw- ua haujlwm hydraulic nruas nres, tsim kom muaj kev tswj xyuas kom zoo thiab ua haujlwm ntev hauv nruab nrab- mus rau - cov tshuab hnyav-xws li forklifts, me cranes, winches, khoom siv, thiab cov khoom siv tsheb. Lub tsev ntawm TYW Series tsim, TYWZ2 (nrog "Z2" qhia qhov thib ob- tiam hloov tshiab) nta kev txhim kho hydraulic efficiency, siab dua torque tso zis, thiab ntxiv cov khoom siv los tswj cov ntawv thov ntau dua (5-20 tons). Nws cov qauv tsim ua ke ua keko taw- pedal actuation(mechanical input hloov mus rau hydraulic quab yuam) nrog lub zognruas{0}}style braking qauv, muab qhov tseem ceeb rau tus neeg teb xov tooj tswj, kev nyab xeeb, thiab kev ntseeg siab nyob rau hauv hnyav kev lag luam ib puag ncig. Hauv qab no yog cov ncauj lus kom ntxaws txog nws cov yam ntxwv, txoj hauv kev ua haujlwm, qhov zoo, kev siv, thiab cov lus qhia tshwj xeeb:
1. Series Overview & Core Function
TYWZ2 Series tuav lub hauv paus "TYW" (T=Ko taw, Y=Hydraulic, W=Nruas)) nrog kev hloov kho dua tshiab rau qhov hnyav dua thiab siv ntau dua. Nws cov haujlwm tseem ceeb suav nrog:
Precision Manual Braking: Tso cai rau cov tswv lag luam los hloov kho qhov kev ncua sij hawm lossis ua tiav nres ntawm ko taw siab, tseem ceeb rau kev ua haujlwm xws li chaw thau khoom (piv txwv li, crane hoists) lossis taug kev tsis sib xws (xws li kev tsim kho forklifts).
Kev ruaj ntseg Load Holding: Kev tuav cov khoom zoo li qub thaum lub pedal raug kaw, txawm tias nyob rau lub sijhawm txuas ntxiv (xws li, tshem tawm cov khoom nruab nrab- huab cua lossis chaw nres tsheb ntawm inclines).
Redundant Safety Braking: Ua hauj lwm raws li ib tug thaub qab system rau automated brakes, kom ntseeg tau tias kev ua hauj lwm txuas ntxiv yam xyuam xim yog thawj lub tshuab ua tsis tiav.
Nrog lub nruas diameters los ntawm 200–500mm thiab torque outputs los ntawm 300–5,000 N·m, series lub hom phiaj nruab nrab - mus rau -hnyav daim ntawv thov yuav tsum tau tib neeg- nyob rau hauv - lub - voj tswj.
2. Txoj Cai Ua Haujlwm
TYWZ2 Series ua haujlwm ntawm kev txhim khohydraulic amplification txoj cai, refining tus thawj tsim rau siab dua thiab smoother teb:
2.1 1. Nres Tso Tawm (Kev ua haujlwm ib txwm muaj)
Thaum cov ko taw pedal tsis koom nrog, sab hauv rov qab springs retract lub nres khau, tsim ib tug 0.3-0.5mm sib txawv ntawm cov khau thiab rotating nruas.
Lub nruas (txuas mus rau lub tshuab tsav lub tog raj kheej) tig ywj siab, ua kom cov cuab yeej txav tau yooj yim (xws li lub forklift mus ncig, lub winch lifting).
2.2 2. Kev Sib Txuas Nres (Controlled Stopping/Holding)
Tswj nres: Kev ntxhov siab ntawm ko taw pedal ua kom muaj kev ua haujlwm siab - hydraulic twj tso kua mis (ua ke rau hauv lub rooj sib txoos pedal). Lub twj tso kua mis no ua kom muaj zog hydraulic siab (8-20 MPa) piv rau cov tiam dhau los, kis tau los ntawm cov hoses ntxiv rau lub nres lub tog raj kheej hydraulic.
Lub tog raj kheej pressurized pushes dual nres khau tiv thaiv lub nruas. Kev sib txhuam ntawm cov hauv ob sab phlu thiab nruas generates braking torque, nrog quab yuam ncaj proportional rau pedal siab - tso cai rau du, adjustable deceleration.
Static tuav: Lub zog pedal xauv (lub zog los yog ratchet mechanism) ruaj lub pedal nyob rau hauv txoj hauj lwm nyuaj siab, tswj hydraulic siab los tuav lub load yam tsis tas tus neeg teb xov tooj siv zog.
2.3 3. Thaum muaj xwm ceev nres
Hauv qhov xwm txheej tseem ceeb, qhov siab tshaj plaws pedal ua rau lub siab tshaj plaws hydraulic tso tawm, tsav cov khau tiv thaiv lub nruas nrog tag nrho - ntsuas torque. Qhov no nres lub tshuab tsis pub dhau tsawg dua los yog sib npaug li 1.2 vib nas this (nyob rau hauv rated load), tiv thaiv kev sib tsoo los yog thauj khoom poob.
Technical Specifications (Tswj Range)
| Parameter | Specification Range |
|---|---|
| Nres Hom | Ko taw- ua haujlwm hydraulic nruas nres (2nd-gen upgrade) |
| Compatible Drum Diameter | 200-500 hli |
| Rated Braking Torque | 300–5,000 N·m |
| Hydraulic System | |
| - Ua haujlwm siab | 8-20 MPa |
| - Hom kua | High -kev ua haujlwm hydraulic roj (ISO VG 68) |
| Friction Lining Khoom | High-kub semi-metallic composite |
| Ua haujlwm kub | -25℃rau 100 degree |
| Pedal Ncig Tebchaws | 60-120 hli |
| Maximum Pedal Force | 50–100 N |
| Chav kawm tiv thaiv | IP65 (nres); IP55 (Pedal Unit) |
| Lub Sijhawm Teb (Full Engagement) | Tsawg dua lossis sib npaug li 1.2 vib nas this |
| Mounting Hom | Flange / Bracket-mounted |
| Qhov hnyav | 25-80 kg (brake + pedal unit) |
TYWZ2 Series sib txuas ua kom muaj zog, ua haujlwm ntev, thiab tswj tus neeg teb xov tooj, ua rau nws yog qhov kev xaiv txhim khu kev qha rau nruab nrab - mus rau - lub tshuab ua haujlwm hnyav uas phau ntawv braking precision thiab kev nyab xeeb yog qhov tseem ceeb.
