YJGQ-60 Series Hydraulic Rail Clamp
🛠️ Cov Khoom Muag Khoom: YJGQ-60 Hydraulic Rail Clamp Lub YJGQ series yog ib qho kev txhim kho ntawm tus qauv YJG series, uas muaj cov qauv muaj zog dua thiab "floating" mechanism los xyuas kom meej txawm tias lub siab faib ntawm txoj kev tsheb ciav hlau. Qauv nab npawb: YJGQ-60 Hom: Hydraulic / Rail Clamp ( Log ...
Hauj lwm lawm
🛠️ Khoom Muag Khoom: YJGQ-60 Hydraulic Rail Clamp
YJGQ series yog ib qho kev txhim kho ntawm tus qauv YJG series, uas muaj cov qauv zoo dua qub thiab ib qho"floating" mechanismlos xyuas kom meej txawm tias kev faib tawm ntawm txoj kev tsheb ciav hlau.
Qauv nab npawb: YWJ-60
Hom: Hydraulic / Rail Clamp (Wheel Edge Nres)
Kev Ua: Nquag kaw (Fail-Safe)
Braking:Caij nplooj ntoos hlav- siv (Kev sib koom ua ke thaum tso tawm hydraulic siab).
Tso Tawm:Hydraulic siab tso tawm lub clamp.
Feature tseem ceeb: "Floating" qauv.Qhov kev tsim no tso cai rau lub clamp caj npab rau nws tus kheej- kho nws lub kaum sab xis, ua kom muaj kev sib cuag nrog lub taub hau tsheb ciav hlau txawm tias muaj kev sib tsoo me ntsis lossis kev tsheb ciav hlau hnav.
📋 Cov Lus Qhia Tshwj Xeeb
| Parameter | Specification rau YJGQ-60 |
|---|---|
| Series | YJGQ (Hydraulic Rail Clamp) |
| Qauv | YWJ-60 |
| Siv tau Log Diameter | 600 hli(Implied los ntawm "60" hauv cov ntsiab lus qauv) |
| Rated Clamping Force | Nws txawv ntawm sub- qauv(eg, YJGQ-60-CR73) |
| Txoj kev Actuation | Hydraulic tso tawm / Caij nplooj ntoos hlav thov |
| Tswj | Chaw nres tsheb Hydraulic (Centralized Control) |
| Cov khoom sib txhuam | High -Kev ua tau zoo Composite hauv ob sab phlu |
✨ Cov yam ntxwv tseem ceeb
Fail-Safe Design (Safety):Nws ua haujlwm ntawm a"Nquag kaw"txoj cai. Yog tias muaj hluav taws xob tsis ua haujlwm lossis hydraulic xau, lub caij nplooj ntoos hlav quab yuam tuaj yeem ua tus nres, xyuas kom lub crane tsis tuaj yeem yob tawm.
Floating Mechanism:Tsis zoo li cov clamps nruj, qhov "floating" tsim tiv thaiv qhov chaw thau khoom thiab ua kom cov kev sib txhuam thaiv kev sib cuag nrog cov tsheb ciav hlau sib npaug, ua kom tuav tau zoo thiab txo qis hnav.
Kev ntseeg siab:Tsim los rau qhov hnyav sab nraum zoov (chaw nres nkoj, yards) nrog kev tiv thaiv plua plav, noo noo, thiab ntsev tsuag.
Teeb liab tawm tswv yim:Nruab nrog txwv kev hloov pauv los muab cov teeb liab hluav taws xob qhia qhov "Braked" lossis "Tshem tawm" xwm txheej, tso cai rau kev cuam tshuam nrog lub crane tswj qhov system.
Phau ntawv tso tawm:Xws li ib phau ntawv tso tawm mechanism rau kev txij nkawm lossis kev ua haujlwm kub ntxhov.
🏭 Ib Daim Ntawv Thov
YJGQ-60 yog siv rau hauv kev lag luam hnyav uas cua tsis kam yog qhov tseem ceeb:
Chaw nres nkoj & Harbor Machinery:Lub nkoj loj - mus rau - ntug hiav txwv cranes thiab mobile harbor cranes.
Sab nraum zoov Rail Crane:Rail-mounted gantry cranes (RMG) thiab thoob log stacker-reclaimers.
Metallurgy:Sab nraum zoov cranes hauv steel mills.
💡 Cov Lus Qhia Ua Haujlwm
Hydraulic System:Yuav tsum muaj lub zog tshwj xeeb hydraulic pob los tsim kom muaj lub siab xav tau los tso tus nres.
Kev tshuaj xyuas:Tsis tu ncua tshuaj xyuas cov kev sib txhuam hauv ob sab phlu rau hnav, raws li kev hnav ntau dhau tuaj yeem txo qhov clamping quab yuam hauv qab qhov kev nyab xeeb.
Rail xwm txheej:Xyuas kom lub taub hau tsheb ciav hlau tsis muaj xeb ntau dhau, dej khov, lossis cov khib nyiab, vim qhov no tuaj yeem cuam tshuam cov coefficient ntawm kev sib txhuam thiab txo qis braking efficiency.
